CHAIN

NO.

Pitch

Width

Roller

Plate

Pin

Ultimate

Strength

Kgf(ave.)

Approx

Weight

Kg/m

P

W

Dia

Height

Thickness

Dia

Length

inch

mm

(min)

R(max)

H(max)

T1

T2

D(max)

F(max)

G(max)

06BH

0.375”

9.525

5.72

6.35

8.26

1.30

1.50

3.28

15.1

18.4

1250

0.45

08BH

0.5”

12.70

7.75

8.51

12.20

2.00

2.00

4.45

19.2

23.2

2400

0.85

10BH

0.625”

15.875

9.65

10.16

14.73

2.00

2.00

5.08

20.6

24.7

3100

1.01

12BH

0.75”

19.05

11.68

12.07

16.13

2.40

2.40

6.12

25.1

29.7

4500

1.42

16BH

1”

25.40

17.02

15.88

24.00

3.10

4.10

9.00

36.1

38.8

9500

3.22
